Construction
2 piece construction
Constructions
Barrel and disc are molded and constructed separately. The new method of jointing parts of the 2-piece wheel together is through welding.
Advantages
The offset can be specially altered millimeter by millimeter to your ideal position of the disc face.
Specification
Sizing
18", 19", 20", 21"
18 INCH [FLAT RIM] - PCD, Width, Disk Type & Offset
PCD:
5H-100 [O disk only]
5H-114.3 [A & O disk only]

Width: 18 X 7.0 to 18 X 12.5

Disk Type:
A disk - Standard brake clearance
O disk - Small brake clearance with deep rim

Offset: Download PDF chart above to see options.
19 INCH [FLAT RIM] - PCD, Width, Disk Type & Offset
PCD:
5H-100 [O disk only]
5H-114.3 [A & O disk only]

Width: 19 X 7.5 to 19 X 12.5

Disk Type:
A disk - Standard brake clearance
O disk - Small brake clearance with deep rim

Offset: Download PDF chart above to see options.
19 INCH [STEP RIM] - PCD, Width, Disk Type & Offset
PCD:
5H-100 [O disk only]
5H-114.3 [A & O disk only]

Width: 19 X 8.0 to 19 X 12.5

Disk Type:
A disk - Standard brake clearance
O disk - Small brake clearance with deep rim

Offset: Download PDF chart above to see options.
20 INCH [FLAT RIM] - PCD, Width, Disk Type & Offset
PCD:  5H-114.3 [A & O disk only]

Width: 20 X 8.0 to 20 X 12.5

Disk Type:
A disk - Standard brake clearance
O disk - Small brake clearance with deep rim

Offset: Download PDF chart above to see options.
20 INCH [STEP RIM] - PCD, Width, Disk Type & Offset
PCD:
5H-100 [O disk only]
5H-114.3 [A & O disk only]

Width: 20 X 8.0 to 20 X 12.5

Disk Type:
A disk - Standard brake clearance
O disk - Small brake clearance with deep rim

Offset: Download PDF chart above to see options.
21 INCH [STEP RIM] - PCD, Width, Disk Type & Offset
PCD:  5H-114.3 [A & O disk only]

Width: 21 X 8.5 to 21 X 12.5

Disk Type:
A disk - Standard brake clearance
O disk - Small brake clearance with deep rim

Offset: Download PDF chart above to see options.
Center Disk colour options
Light Metallic Gold [LMG] - Standard
Cut Clear [MSP] - Standard
Glim Black [GBK] - Additional cost
Trans Gray Polish [TGP] - Additional cost
Pierce bolt [rivet] colour options
Chrome - Standard
Black - Additional cost
Gold - Additional cost
Barrel [rim] colour options
Polished anodized rim - Standard
Brushed anodized rim - Additional cost
Gloss or Matt Bronze anodized rim - Additional cost
Gloss or Matt Black anodized rim - Additional cost
Included with each wheel
1 X Air Valve
1 X Centre Cap
Optional items
Center caps options
LANVEC CAP [5-114.3]
LANVEC CAP [5-100]
LANVEC CHROME CAP [5-114.3]
LANVEC CHROME CAP [5-100]
Outer rim / lip colour options
POLISHED ANODIZED
BRUSHED ANODIZED
GLOSS BLACK ANODIZED
MATT BLACK ANODIZED
GLOSS BRONZE ANODIZED
MATT BRONZE ANODIZED
Wheels valves options
CHROME [V24C]
BLACK [V24K]
CHROME [V39A]
BLACK [V39K]
